ZF5645+SJ400
Specification:
| Model | ZF-P1600 | ZF-CH450-1200 |
| Machine size L*W*H(mm) | 1773*1725*1145 | 2100*774*1185 |
| Power supply | 1P/220V/50HZ/0.2KW | 1P/220V/50HZ/0.1KW |
| Net weight | 290KG | 150KG |
Introduction
This packaging production line is mainly used for flat packaging of OPP sealing tape, which can be combined packaging of 8, 6, 4, and 2 rolls and single packaging. It can also be used for packaging cloth tape, aluminum clamp tape, mesh tape, etc.
| Model | ZF-A5645 |
| Machine size L*W*H(mm) | 1795*880*1570 |
| Sealing blade size L*W(mm) | 565*460 |
| Product size range L*W*H(mm) | (90-450)*(50-350)*(10-120) |
| Power supply | 1P/220V/50HZ/3KW |
| Net weight | 360KG |
| Model | ZF-SJ400 |
| Machine size L*W*H(mm) | 1500*705*1430 |
| Product size range W*H(mm) | 300*200 |
| Power supply | 1P/220V/50HZ/9KW |
| Net weight | 320KG |
Features
1. 6 rolls of flat paved packaging can be as fast as 20 packs per minute, 35 packs/min for single roll.
2. It is easy to adjust the width and do not need any tools to change the required size quickly.
3. With blade rest using the solid aluminum , the sealing balde is designed for integral knife and it is not easy to deform. Sealing position is stable and the sealing & cutting speed is fast
4. High efficiency and energy saving shrinkage furnace can be selected to save electricity.
5. The disk and push product belt are all made of non viscose Teflon material, which will never be viscose and durable.
6. It can realize unmanned operation by connecting an automatic slitting machine to a manual one.
